Automatic Mains Failure (AMF) Panels: Reliable Power Transition Solutions

At Plus 3 Group, we are recognized as a premier manufacturer and supplier of high-performance Automatic Mains Failure (AMF) panels. Our solutions are engineered for exceptional fabrication quality and long-term durability, ensuring your operations remain powered even during critical grid failures.

An AMF board, often integrated with Automatic Transfer Switch (ATS) technology, serves as the intelligent interface between your primary utility power and your backup generator. This system eliminates the need for manual intervention, providing a seamless transition that protects both your equipment and your productivity.


How AMF and ATS Panels Work
Our panels provide 24/7 monitoring of the incoming AC mains supply. The process follows a sophisticated logic sequence:

Power Failure Detection: The panel instantly senses a drop or total loss in mains voltage.

Automatic Activation: It triggers the standby generator to start immediately without human intervention.

Seamless Load Transfer: Once the generator reaches the required frequency and voltage, the ATS safely shifts the building’s electrical load from the mains to the generator.

System Restoration: When stable mains power returns, the panel manages the re-transfer of the load back to the utility grid.

Cool-Down Cycle: The system continues to run the generator for a preset "cooling period" before shutting it down, which extends the engine's operational life.

Key Features of Plus 3 Group AMF Panels
Precision Monitoring: Real-time tracking of voltage, frequency, and phase balance for both mains and generator sources.

User-Friendly Interface: Equipped with digital controllers and clear status indicators for easy operation and diagnostics.

Safety Interlocks: Built-in electrical and mechanical interlocks to prevent simultaneous connection of both power sources.

Customizable Logic: Programmable timers for start-up, warm-up, and cool-down cycles tailored to your specific generator requirements.

Technical Specifications
Current Rating: Scalable designs ranging from 32A up to 4000A.

Protection Level: Standard IP54 for indoor use and IP65 for outdoor-ready enclosures.

Fabrication: Constructed from high-grade CRCA steel with a durable 7-tank powder-coated finish to prevent corrosion.

Compliance: Fully assembled in accordance with international safety and industrial quality regulatory norms.


Versatile Industrial Applications
Plus 3 Group AMF panels provide the reliability needed to safeguard against the high costs of unplanned downtime in sectors such as:

Healthcare: Ensuring critical life-support systems in hospitals never lose power.

Data Centers: Protecting sensitive digital infrastructure from sudden outages.

Manufacturing: Preventing production loss in industries like textiles, chemicals, and automotive.

Commercial Buildings: Maintaining elevators, lighting, and HVAC in residential and corporate complexes.

By integrating a Plus 3 Group AMF panel into your electrical infrastructure, you ensure a resilient and automated response to power instability, keeping your business operational around the clock.
